ISO 9001 Approved Linear Control Swiss Type CNC Lathe Vertical Machining Center

Basic Info

Model NO.	KDVM600L
Performance Classification	High-End CNC Machine Tools
Certification	CE, ISO 9001
Condition	New
Table Size	750*400mm--1130*510mm
Repearability	+-0.003
Transport Package	Export Standard Wooden Pallets
Specification	CE, ISO9001, SGS
Trademark	KD
Origin	Zhejiang China
HS Code	8457101000
Production Capacity	523

Product Description

ISO 9001 Approved Linear Control swiss type cnc lathe Vertical Machining Center

Product Description

Product Specifications

MODELS	KDVM600L
TRAVEL
X axis	600mm
Y axis	430mm
Z axis	500mm
Spindle center to column	484mm
Spindle end to table	90-570mm
TABLE
Tablesize	720×400mm
T-slot(width×number×space)	18mm×3×110mm
Max.table loading	500kg
SPINDLE
Taper bore of spindle	BT40
Spindle power	9kw
Spindle speed	8000rpm
Driving by belt or gears	Belt
Kind of gearbox	without gearbox
Cutter removal from spindle	Pneumatic
FEED
X/Y/Z fast feed	36/ 36/ 36m/min
Torque axis motors	11/ 11/ 11Nm
ATC
Type (disc/carousel)	Carousel
Tool number	20
Max. tool size (With adjacent tool)	Ф76mm
Max. tool size (Without adjacent tool)	Ф150mm
Max.tool length	300mm
Max.tool weight	8kg
Time (tool-tool)	2s
ACCURACY
Positioning	≤0.008
Repeatability(X/Y/Z)(ISO)	≤0.004mm
OTHERS
Min.Input	0.001mm
Coolant pump power	370w
Overall dimension	3550x2100x2400mm
Net weight	3900kg
